​VINYL FENCE STYLES & SPECS
FA-1 Style
Height: 72"
Widths: Available 72", 96"
Post: 5"x5"(A01)
Cap: New England (C51)
Rail: (A02, A02B)
Top & Bottom: 2" x 6"
Metal Insert: Bottom (optional)
Planks: (A03)
11"x7/8", Tongue & Groove
U Channel: 7/8"x3/4" (A27)
Matching Gate available
FA-2 Style
Tell people more about this item. What's it about and what makes it interesting? Give people the info they need to go ahead and take the action you want.
To make this item your own, click here > Add & Manage Items.
FA-3 Style
Height: 72"
Widths: Available 72", 96"
Post: 5"x5"(A01)
Cap: New England (C51)
Rail:(A25, A24, A02B)
Middle & Bottom: 2" x 6"
Top: 2" x 3-1/2"
Metal Insert: Bottom (optional)
Lattice:(A26)
Planks:(A03)
11"x7/8", Tongue & Groove
U Channel: 7/8"x3/4" (A27)
Matching Gate available
FA--4 Style
Height: 72"
Widths: Available 72", 96"
Post: 5"x5"(A01)
Cap: New England (C51)
Rail:(A14, A02, A02B)
Middle & Bottom: 2" x 6"
Top: 2" x 3-1/2"
Metal Insert: Bottom (optional)
Picket:1-1/2"x1-1/2" (A11)
Planks:(A03)
11"x7/8", Tongue & Groove
U Channel: 7/8"x3/4" (A27)
Matching Gate available
FA-5 Style
Height: 72"
Width: Available 72", 96"
Post: 5"x5"(A01)
Cap: New England (C51)
Rail:(A14, A02, A02B)
Middle & Bottom: 2" x 6"
Top: 2" x 3-1/2"
Metal Insert: Bottom (optional)
Picket:1-1/2"x1-1/2" (A11, C15)
Planks:(A03)
11"x7/8", Tongue & Groove
U Channel: 7/8"x3/4" (A27)
Matching Gate available
FB-1 Style
Height: 72"
Width: Available 72", 96"
Post: 5"x5"(A01)
Cap: New England (C51)
Rail:(A14, A02, A02B)
Middle & Bottom: 2" x 6"
Top: 2" x 3-1/2"
Metal Insert: Bottom (optional)
Picket:1-1/2"x1-1/2" (A11, C15)
Planks:(A03)
11"x7/8", Tongue & Groove
U Channel: 7/8"x3/4" (A27)
Matching Gate available
FB-2 Style
Height: Available 48", 36"
Width: Available 72", 96"
Post: 4"x4"(A08)
Cap: New England (C41)
Rail:
Bottom: 2" x 6" (A02B)
Top and Middle: 2" x 3-1/2" (A14)
Metal Insert: Bottom (optional)
Picket:1"x1" (A12, C11)
Matching Gate available
FB-3 Style
Height: 48", 60", 72"
Width: 72", 96"
Post: 5" (A01)
Cap: New England (C51)
Rail:
Bottom: 2" x 6" (A02B)
Top: 2" x 3-1/2" (A14)
Metal Insert: Bottom (option)
Picket: 1-1/2" x 1-1/2" (A11)
Pickets Spacing: 2-1/2"
Matching Gate available
FB-4 Style
Height: 48", 60", 72"
Width: 72", 96"
Post: 5" (A01)
Cap: New England (C51)
Rail:
Bottom: 2" x 6" (A02B)
Top: 2" x 3-1/2" (A14)
Metal Insert: Bottom (optional)
Picket: 1-1/2" x 1-1/2" (A11,C15)
Pickets Spacing: 2-1/2"
Matching Gate available
FB-5 Style
Height: 48", 60", 72"
Width: 72", 96"
Post: 5" (A01)
Cap: New England (C51)
Rail:
Bottom: 2" x 6" (A02B)
Top: 2" x 3-1/2" (A14)
Metal Insert: Bottom (optional)
Picket: 1-1/2" x 1-1/2" (A11,C15)
Pickets Spacing: 2-1/2"
Matching Gate available
FC-1 Style
Height: 48", 60", 72"
Width: 72", 96"
Post: 4" or 5" (A08 or A01)
Cap: New England (C41 or C51)
Rail:
Bottom: 2" x 6" (A02)
Top & Middle: 2" x 3-1/2" (A14)
Metal Insert: Bottom (optional)
Picket: 7/8" x3" (A15) or 7/8" x 6" (A16)
Pickets Spacing: 2"
Matching Gate available
FC-2 Style
Height: 48", 60", 72"
Width: 72", 96"
Post: 4" or 5" (A08 or A01)
Cap: New England (C51)
Rail:
Bottom: 2" x 6" (A02)
Top & Middle: 2" x 3-1/2" (A14)
Metal Insert: Bottom (optional)
Picket: 7/8" x3" and 1x1" (A15, A12)
Pickets Spacing: 2"
Matching Gate available
FC-3 Style
Height: 48", 60"
Width: 72", 96"
Post: 5" (A01)
Cap: New England (C51)
Rail: 1-1/2" x 5-1/2" (A13)
Matching Gate available
FC-4 Style
Height: 48", 60", 72"
Width: 72", 96"
Post: 4"or 5" (A08 or A01)
Cap: New England (C41 or C51)
Rail:
Bottom: 2" x 6" (A02)
Top: 2" x 3-1/2" (A14)
Metal Insert: Bottom (optional)
Picket: 7/8" x3" (A15, C31 or C32)
Pickets Spacing: 2.5"
Matching Gate available
FC-5 Style
Height: 48", 60", 72"
Width: 72", 96"
Post: 4"or 5" (A08 or A01)
Cap: New England (C41 or C51)
Rail:
Bottom: 2" x 6" (A02)
Top: 2" x 3-1/2" (A14)
Metal Insert: Bottom (optional)
Picket: 7/8" x3" (A15, C31 or C32)
Pickets Spacing: 2.5"
Matching Gate available
